Bought a 96 Miata today for my girlfriend, looked under it after I got home and the supports that run under the diff that I think are the subframe brace (link to one on eBay below) are missing and a unibody rail looks crushed by a jack. Should I be concerned? It drove 2 hours home just fine. [this piece ](https://www.ebay.com/itm/284426084903?chn=ps&_trkparms=ispr%3D1&amdata=enc%3A1o11ntPsGQpqVn6j7SFEphw43&norover=1&mkevt=1&mkrid=711-117182-37290-0&mkcid=2&itemid=28... Mazda Miata MX-5 2006, Front Sway Bar Link Nut by Genuine®. Quantity: 1 per Pack. If your suspension parts are in need of repair, don't compromise the performance and safety of your car with suspect, off-brand replacement parts from...
